| Standardization: | Numberical Symbol: | |
| AWS 5.15 | ERNiCl |
|
| ASME SFA 5.15 | UNS N02215 |
|
| AWS Chemical Composition: | % | |
| Ni | 90.00 | |
| Mn | 2.50 | |
| C | 1.00 | |
| Cu | 4.00 | |
| Fe | 4.00 | |
| Si | 0.75 | |
| S | 0.03 | |
| Total others | 1.00 | |
| Standard values of the weld metal: | ||
| Elongation | % | 40 |
| Tensile strength | MPa | 460 |
| Yield strength | MPa | 250 |
| Applications: | ||
| The Nickel Alloy 99 is used for the welding of cast irons. This filler metal is extensively employed to repair cast irons. It can also be used for overlay and buildup.However, dilution from the castings influences the mechanical properties of the metal. The welds of the Nickel Alloy 99 are easily machinable. A preheat and interpass temperature of 350°F (175°C) minimum is recommended during welding. | ||
| Make up: | ||
| Diameter: 1.60 -2.40 - 3.20 |
||
| Rods:1.60 - 9.6 mm x 914/1000 mm |
||
| Further make ups on request. |
||
