Standardization:Numberical Symbol: GB/T9460-2008 SCu6240 AWS A5.7:2007 ERCuAl-A3 BS EN ISO24373:2009 CuAl11Fe3 AWS Chemical Composition:% Cu incl.agbal. Zn0.10 Fe2.00-4.50 Si0.10 Al10.00-11.50 Pb0.02 Total othersmax 0.50 Physical properties of materials: Density Kg/m^3 7.7 Melting range ℃ 1030-1045 Thermal conductivity W/m.K 55 Electrical conductivity S.m/mm^2 6.7-7.7 Coefficient of thermal expansion 10^-6/K(20-300℃)16.7 Standard values of the weld metal: Elongation…
Standardization:Numberical Symbol: GB/T9460-2008 SCu6180 AWS A5.7:2007 ERCuAl-A2 BS EN14640:2005Cu6180 DIN 1733SG-CuAl10Fe BS EN14640:2005:% Cu incl.agbal. Zn0.02 Fe0.50-1.50 Si0.10 Al8.50-11.00 Pb0.02 Total othersmax 0.40 Physical properties of materials: Density Kg/m^3 7.6 Melting range ℃ 1030-1040 Thermal conductivity W/m.K 55 Electrical conductivity S.m/mm^2 6.5-7.5 Coefficient of thermal expansion 10^-6/K(20-300℃)17.0 Standard values of the weld metal: Elongation %35…
Standardization:Numberical Symbol: GB/T9460-2008 SCu5211 BS EN14640:2005 Cu 5211 GB Chemical Composition:% Cu incl.agbal. Znmax 0.10 Sn9.00-10.00 Mn0.10-0.50 Femax 0.10 Si0.10-0.50 Pmax 0.10 Almax 0.01 Pbmax 0.02 Total othersmax 0.50 Physical properties of materials: Density Kg/m^3 8.7 Melting range ℃ 887-1020 Thermal conductivity W/m.K 47 Electrical conductivity S.m/mm^2 5-6 Coefficient of thermal expansion 10^-6/K(20-300℃)18.0 Standard values…
Standardization:Numberical Symbol: GB/T9460-2008 SCu6100 AWS A5.7:2007 ERCuAl-A1 BS EN ISO24373:2009CuAl7 AWS Chemical Composition:% Cu incl.agbal. Zn0.20 Mn0.50 Si0.10 Al6.00-8.50 Pb0.02 Total othersmax 0.50 Physical properties of materials: Density Kg/m^3 7.7 Melting range ℃ 1030-1040 Thermal conductivity W/m.K 65 Electrical conductivity S.m/mm^2 7-9 Coefficient of thermal expansion 10^-6/K(20-300℃)17.0 Standard values of the weld metal: Elongation %40…
Standardization:Numberical Symbol: GB/T9460-2008 SCu5180A AWS A5.7:2007 ERCuSn-A BS EN ISO24373:2009CuSn6P DIN 1733SG-CuSn6 AWS Chemical Composition:% Cu incl.agbal. Sn4.00-6.00 P0.10-0.35 Al0.01 Pb0.02 Total others0.50 Physical properties of materials: Density Kg/m^3 8.7 Melting range ℃ 910-1040 Thermal conductivity W/m.K 75 Electrical conductivity S.m/mm^2 6-7 Coefficient of thermal expansion 10^-6/K(20-300℃)18.1 Standard values of the weld metal: Elongation %20…
Standardization:Numberical Symbol: GB/T9460-2008 SCu5210 AWS A5.7:2007 ERCuSn-C BS EN14640:2005 Cu 5210 Composition(standard values):% Cu incl.agbal. Zn0.20 Sn7.00-9.00 Fe0.10 P0.10-0.35 Al0.01 Pb0.02 Total others0.50 Physical properties of materials: Density Kg/m3 8.8 Melting range ℃ 875-1025 Thermal conductivity W/m.K 66 Electrical conductivity S.m/mm2 6-8 Coefficient of thermal expansion 10^-6/K(20-300℃)18.5 Standard values of the weld metal: Elongation %20…
Standardization:Numberical Symbol: GB/T9460-2008SCu6511 BS EN14640:2005 Cu 6511 GB Chemical Composition:% Cu incl.agbal. Znmax 0.20 Sn0.10-0.30 Mn0.50-1.50 Femax 0.10 Si1.50-2.00 Pmax 0.02 Almax 0.01 Pbmax 0.02 Total othersmax 0.5 Physical properties of materials: Density Kg/m^3 8.7 Melting range ℃ 1030-1050 Thermal conductivity W/m.K 40 Electrical conductivity S.m/mm^2 4.7-5.3 Coefficient of thermal expansion 10^-6/K(20-300℃)18.1 Standard values of…
Standardization:Numberical Symbol: GB/T9460-2008SCu6560 AWS A5.7:2007ERCuSi-A BS EN ISO24373:2009CuSi3Mn1 DIN 1733SG-CuSi3 AWS Chemical Composition:% Cu incl.agbal. Zn1.00 Sn1.00 Mn1.50 Fe0.50 Si2.80-4.00 Al0.01 Pb0.02 Total others0.50 Physical properties of materials: Density Kg/m^3 3.5 Melting range ℃ 965-1030 Thermal conductivity W/m.K 35 Electrical conductivity S.m/mm^2 3.5-4.0 Coefficient of thermal expansion 10^-6/K(20-300℃)18.1 Standard values of the weld metal: Elongation…
During the storage process of welding wire products, they are basically also methodical. When storing, they must be guaranteed that they are all stored in some dry environment, and they must avoid some moisture. Or where there is more liquid, the welding wire can not be stored with some other acidic liquid, or alkaline liquid. The welding…
The electrode coating is made up of various minerals, iron alloy organic compounds and chemical products (such as sodium silicate). The composition of the electrode coating is quite complex. There are seven or eight kinds of composition in the electrode coating. The composition of the electrode coating is very complicated. According to different uses, the…
